Understanding USB Types - Connector, Speed, Version, and More

·652 words·4 mins· loading · ·
Computer Hardware USB USB Types USB Connector USB Speed USB Versions

On This Page

Table of Contents
Share with :

Understanding USB Types
#

USB (Universal Serial Bus) is port/interface for data communcation between laptop/destop and external device (harddisk, mice, display, printer etc). There are many types of USB and in this article we are trying to understand those?

USB Connector Types (Physical Shape)
#

These define the shape and size of the USB plug and port:

Type Image (Conceptual) Description
USB Type-A 🔲 Standard rectangle Most common, found on desktops, laptops, TVs
USB Type-B ⬛ Square (with bevel) Used in printers, scanners, older devices
USB Mini-B 🔹 Small trapezoid Used in older cameras, GPS units
USB Micro-B 🔸 Flatter & thinner Found on older phones, external drives
USB Type-C ⭕ Oval, reversible Modern standard – supports fast data, video, charging

👉 Type-A and Type-C are the most relevant today.

USB & Thunderbolt Standards Overview
#

Standard Max Speed Marketing Name Common Connectors Video Output Charging Capability Notes
USB 1.1 12 Mbps Full-Speed USB Type-A, Type-B No No Obsolete; used for basic peripherals like keyboards and mice.
USB 2.0 480 Mbps Hi-Speed USB Type-A, Type-B, Mini-B, Micro-B No Limited (up to 2.5W) Widely used; suitable for peripherals like keyboards, mice, and flash drives.
USB 3.0 / 3.1 Gen 1 / 3.2 Gen 1 5 Gbps SuperSpeed USB Type-A (blue), Type-B, Micro-B, Type-C No Yes (up to 4.5W) Enhanced data transfer rates; backward compatible with USB 2.0.
USB 3.1 Gen 2 / 3.2 Gen 2 10 Gbps SuperSpeed+ USB Type-A, Type-C Optional (via DisplayPort Alt Mode) Yes (up to 15W) Doubled speed over previous generation; supports video output with compatible devices.
USB 3.2 Gen 2x2 20 Gbps SuperSpeed+ USB 20Gbps Type-C Optional (via DisplayPort Alt Mode) Yes (up to 15W) Utilizes two 10 Gbps lanes; requires compatible hardware for full speed.
USB4 20/40 Gbps USB4 Type-C Yes (via DisplayPort 1.4a/2.0 Alt Mode) Yes (up to 100W via Power Delivery) Based on Thunderbolt 3 protocol; supports dynamic bandwidth allocation between data and video.
USB4 Version 2.0 80 Gbps USB4 Version 2.0 Type-C Yes (via DisplayPort 2.1 Alt Mode) Yes (up to 100W via Power Delivery) Introduces PAM3 signaling; supports asymmetric data transfer (up to 120 Gbps in one direction).
Thunderbolt 3 40 Gbps Thunderbolt 3 Type-C Yes (up to dual 4K displays) Yes (up to 100W via Power Delivery) Combines PCIe and DisplayPort; supports daisy-chaining up to six devices.
Thunderbolt 4 40 Gbps Thunderbolt 4 Type-C Yes (up to dual 4K or one 8K display) Yes (up to 100W via Power Delivery) Ensures minimum requirements: 40 Gbps speed, dual 4K display support, and charging capabilities.
Thunderbolt 5 80/120 Gbps Thunderbolt 5 Type-C Yes (up to dual 8K displays) Yes (up to 240W via Power Delivery 3.1) Utilizes USB4 Version 2.0; supports asymmetric bandwidth (120 Gbps in one direction).

Notes:

  • Connector Types: While USB Type-A is the traditional rectangular connector, USB Type-C is a newer, reversible connector that supports higher data transfer rates and power delivery.([WIRED][1])

  • Video Output: USB standards that support video output do so via DisplayPort Alternate Mode, allowing the USB port to transmit video signals to external displays.

  • Charging Capability: Power Delivery (PD) specifications allow for higher power transfer over USB connections, enabling faster charging of devices.([Wikipedia][2])

Port Markings (and What They Mean)
#

Marking Meaning
SS or SS+ SuperSpeed (USB 3.x)
Thunderbolt ⚡ Thunderbolt 3 or 4 (usually Type-C)
DP symbol (🖥) Supports DisplayPort (video output)
Charging Icon (🔋) Supports charging/power delivery

Real-World Examples on Modern Laptops
#

Port Type Use Case
USB-A 3.2 Connecting flash drives, keyboards
USB-C (3.2/4/Thunderbolt) Charging, display output, fast data
USB-C PD Power Delivery – can charge your laptop or phone
USB-C w/ DP Can connect to monitors
Thunderbolt 4 (USB-C) Full-speed docking, external GPU, 4K monitors

How to Identify What You Have?
#

  1. Look for labels next to ports (like SS, , or PD)
  2. Check your specs from manufacturer’s website
  3. Use software like Speccy or HWiNFO for deeper insight

A Diagram
#

Credit to https://techterms.com
